The Ubiquiti UniFi U7 In-Wall enhances wireless connectivity in indoor settings. With a maximum data transfer rate of 4.3 Gbps and support for wireless protocols including Wi-Fi 6 and Wi-Fi 7, this wall-mountable access point ensures fast and reliable connections for over 200 connected devices. Its internal antenna offers efficient coverage across 115 square meters, suitable for both residential and commercial applications. Equipped with features such as 2×2 MU-MIMO technology, band steering, and Fast Roaming, the U7 ensures smooth performance in busy networks. This device supports various authentication methods and encryption algorithms, assuring secure access for all users. Built to withstand different environmental conditions, the U7 operates effectively from -30°C to 40°C with a humidity range of 5 to 95%.
- Provides high-speed wireless connectivity with up to 4.3 Gbps data transfer rate
- Supports over 200 connected devices and advanced wireless protocols
- Features internal antenna for efficient coverage up to 115 sq.m
- Offers secure access with multiple authentication methods and encryption
- Designed for various environmental conditions with a wide operating temperature range
Dimensions
137 x 98.7 x 30.2 mm
(5.4 x 3.9 x 1.2″)
WiFi Standard
WiFi 7
Spatial Streams
4
Coverage Area
115 m2 (1,250 ft2)
Max. Client Count
200+
Uplink
2.5 GbE
Mounting
Wall
(Metal Wall Mount Included)
Power Method
PoE
PoE+ (Required for PoE output)
MIMO
5 GHz
2 x 2 (DL/UL MU-MIMO)
2.4 GHz
2 x 2 (DL/UL MU-MIMO)
Max. Data Rate
5 GHz
4.3 Gbps (BW240)
2.4 GHz
688 Mbps (BW40)
Antenna Gain
5 GHz
8 dBi
2.4 GHz
4 dBi
Max. TX Power
5 GHz
24 dBm
2.4 GHz
23 dBm
Max. BSSIDs
8 per Radio
Supported Data Rates
802.11be (WiFi 7)
7.3 Mbps to 4.3 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240)
802.11ax (WiFi 6)
7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 1.7Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160)
802.11n
6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
Wireless Meshing
Yes
Band Steering
Yes
802.11v BSS Transition Management
Yes
802.11r Fast Roaming
Yes
802.11k Radio Resource Management (RRM)
Yes
Advanced Radio Management
Yes
Passpoint (Hotspot 2.0)
Yes
Captive Hotspot Portal
Yes
Private Pre-Shared Key (PPSK)
Yes
WiFi Speed Limiting
Yes
Client Device Isolation
Yes
WiFi Schedules
Yes
RADIUS over TLS (RadSec)
Yes
Dynamic RADIUS-assigned VLAN
Yes
Max. Power Consumption
13W (Excluding PoE output)
Supported Voltage Range
42.5—57V DC
Networking Interface
(3) 2.5 GbE RJ45 ports
Weight
400 g (14.1 oz)
Management
Ethernet
Built-In Switch
(1) PoE+ input and
(1) PoE output
Enclosure Material
Polycarbonate, aluminum alloy
Mount Material
Aluminum alloy
LEDs
White/Blue
Certifications
CE, FCC, IC
