The NETGEAR SOHO Ethernet Unmanaged Switches provide easy and affordable network connectivity to small offices and home/offices. They are easy to use, reliable, and rugged with metal enclosures. Power-over-Ethernet (PoE) support is also available for supplying both power and data across a single CAT-5 ethernet cable to devices such as IP security cameras, VoIP phones, wireless access points, etc. With these Plug-and-Play switches, you can quickly and easily expand your network connections to multiple devices, with no configuration required.
- Energy-efficient technology for power savings
- Auto-MDI/MDIX eliminates the need for crossover cables
- Non-blocking switching architecture for maximum throughput at wire speed
- Auto-negotiation for automatic connection at the highest common speed between switch and an end device
- Power-over-Ethernet (PoE) option available for powering IP Security Cameras, VoIP phones, wireless access points, and other PD-powered devices
- Fanless design for silent operation
Device Type Switch – 24 ports – unmanaged
Enclosure Type Rack-mountable
Subtype Gigabit Ethernet
Ports 16 x 10/100/1000 (PoE+) + 8 x 10/100/1000
Power Over Ethernet (PoE) PoE+
PoE Budget 190 W
Performance Non-blocking bandwidth: 48 Gbps
Packet buffer size: 192 KB
Forwarding performance (64-byte packet size): 1448000 pps
Latency (64-byte packets): 4 µs
MAC Address Table Size 8K entries
Jumbo Frame Support 10000 bytes
Features Auto-negotiation, auto-uplink (auto MDI/MDI-X), DiffServ support, half duplex mode, full duplex mode, Energy Efficient Ethernet, CoS, 1 fan, WRR
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3at, IEEE 802.3az
Power AC 120/230 V (50/60 Hz)
Dimensions (WxDxH) 33 cm x 20.6 cm x 4.3 cm
Weight 2.44 kg
Localisation United Kingdom, Europe
Manufacturer Warranty 3-year warranty
